FTTH XPON 1GE plus CATV ONU

FTTH XPON 1GE plus CATV ONU
Tiedot:
1GE plus CATV E/GPON ONU is designed for fulfilling FTTH and triple play service demand of fixed network operators or cable operators. It meets telecom operators FTTO (office), FTTD (Desk), FTTH (Home) broadband speed, SOHO broadband access, video surveillance and other requirements. It is based on the mature stable, cost-effective Gigabit EPON technology, and has high ratio of performance to price, the technology of Layer 2/3, integrated CATV and configuration flexibility. They are highly reliable and easy to maintain, with guaranteed QoS for different service, and fully compliant with technical regulations such as IEEE802.3ah and technical requirement of EPON Equipment from China Telecom.
Lähetä kysely
Kuvaus
Lähetä kysely

ominaisuudet

●Plug and play, integrated auto detecting, auto configuration, and auto firmware upgrade technology.

●Full compliance to IEEE 802.3ah specification OAM function.

●Support rich VLAN, DHCP Server and IGMP snooping multicast feature.

●Advantage traffic management

●Advanced Dynamic Bandwidth Allocation (DBA)

●The WAN port supports bridge or router mode.

●Advanced L2 features QinQ VLAN QoS support.

●Support NAT, Firewall function.

●Support Console/ Telnet/ NMS management interface for ease of operation and maintenance.

●Support 2K MAC address table.

●Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset


Erittely

PON interface

1 G/EPON port(EPON PX20 plus  and GPON Class B plus )

Aallonpituus

Tx1310nm, Rx 1490nm, CATV 1550nm.

Herkkyys

<>

Ylikuormitus

> -3dBm(PX20 plus ).

Optical interface

1 PON interface, 1 CATV interface, SC/APC connector

LAN interface

110/100/1000Mbps auto adaptive Ethernet interfaces Full/Half. RJ45 connector.

RF interface

1 RF output interface.

LED

9, For Status of POWER, LOS, PON, GE, CATV .

Operating condition

Temperature: -5 degree -55 degree
Humidity: 10 percent -90 percent （non-condensing）

Storing condition

Temperature :-30 degree -60 degree
Humidity :10 percent -90 percent （non-condensing）

Power supply

DC 12V

Power consumption

Vähemmän tai yhtä suuri kuin 10 W

Ulottuvuus

110mm90mm25mm（LWH）


 Network Construction

Tilaustiedot

                Product Name                Product Model                Descriptions
                XPON ONU                CATV E/GPON ONU                1GE Ethernet interface, 1 E/GPON interface, plastic casing, 1RF CATV,external power supply adapter DC 12V 1A



FTTH XPON 1GE+CATV ONU1

FTTH XPON 1GE+CATV ONU

FTTH XPON 1GE+CATV ONU2
